L956F 动臂油缸(3731CH) Lift arm cylinder F1310-4120009098

1 4120005999001 缸筒总成24A139210 Cylinder tube Y 1

2 4120009098001 活塞杆总成24A116910 Piston rod Y 1

3 4120005999003 缸盖24C101150 Cover Y 1

4 4120005980010 衬套24S290501 Bushing Y 1

5 4120005980008 钢丝挡圈-孔用24C090220 Retaining ring Y 1

6 4120005999004 密封件-缓冲24H009004 Sealing ring N 1

7 4120005999005 密封件-活塞杆24F209003 Sealing ring N 1

8 4120008479002 挡圈-U形圈24E00902C Retaining ring N 1

9 4120004336016 密封件-防尘24D209002 Sealing ring N 1

10 4120005980009 钢丝挡圈-孔用24C090240 Retaining ring Y 1

11 4120005999008 O形圈24K11600A O-ring N 1

12 4120009098002 挡圈-O形圈24M11700C O-ring N 1

13 4120005999010 O形圈24K316701 O-ring N 1

14 4120005999011 活塞24C102100 Piston Y 1

15 4120005999012 密封件-活塞24P217002 Sealing ring N 1

16 4120005999013 O形圈24K10900A O-ring N 1

17 4120008479003 挡圈-O形圈24M10950C O-ring N 1

18 4120005999015 支承环24G217021 Sealing ring N 2

19 4120005980011 活塞背母24C103050 Nut Y 1

20 4090000168 钢球GB308-5-GCr6 Ball Y 1

21 4120005872008 螺钉-内六角凹端紧定24T908161 Screw Y 1

22 4120007579004 轴套24C051050 Sleeve Y 1

23 4120005999017 销边防尘24R308030 Sealing ring Y 2

24 4120005999018 螺钉-内六角圆柱头24T518755 Screw Y 12

25 4120005685012 固定座24C003020 M16 Anchorage Y 1

26 4120009098003 密封件包24A105070S Sealing kit Y 1
