L956F 减压阀总成 Pressure reducing valve C0561-2905001368

1 4011000289 螺栓GB5783-M6*16EpZn-8.8 Bolt Y 6

2 4015000207 垫圈GB97.1-6EpZn-300HV Washer Y 6

3 29050015401 端盖 Cover N 2

4 4030000211 O形圈GB3452.1-30.0*2.65G O-ring Y 4

5 29050015391 间隔套 Spacer sleeve N 2

6 29050015371 弹簧 Spring Y 2

7 29050015361 弹簧 Spring Y 2

8 29050015351 阀体 Valve housing N 1

9 29050015411 调整塞 Trimmer plug N 2

10 29050015421 阀杆 Valve slide N 2

11 29050015381 弹簧 Spring Y 2

12 29050015431 弹簧导向套 Spring guide N 2

13 4015000295 挡圈GB894.1-14-65Mn Retaining ring Y 2
