L956F 散热器总成L956F-W（43305） Radiator A0394-4110003613

1 4110003612001 焊接组合框架KZ9113582A Radiator frame N 1

2 4110003075002 防护网HB0232 Fan guard Y 2

3 4110003613001 导风罩DB0464 Fan shroud N 1

4 4110003075006 中冷器S9112594A Air cooler Y 1

5 4110003075007 水散S9112594B Radiator Y 1

6 4110002945006 水箱盖711001 Cover Y 1

7 4110003075008 液压油散热器S9112594C Oil cooler Y 1

8 4110003075010 传动油冷却器S9112594D Oil cooler Y 1

9 4110003612002 旋转支架KZ9112594B Bracket N 1

10 4110002945015 法兰面螺栓614212 Screw N 30

11 4110002945007 放水阀739001 Valve Y 1

12 4110002506023 放水管8000080800 Hose Y 1

13 4110002286007 卡箍990002 Clamp N 1

14 4110003075014 六角头螺栓610205 Screw N 6

15 4110002943004 弹垫632300 Spring washer N 10

16 4110001688022 平垫630330 Plain washer N 20

17 4110003075015 外六角螺塞641306 Plug N 1

18 4110003075016 组合垫片634009 Shim N 1

19 4110003075019 六角螺母621400 Nut N 2

20 4110003075020 锁扣橡胶垫720044 Rubber mat N 2

21 4110003075021 锁扣安装轴330530 Shaft N 2

22 4110003075022 锁扣定销330531 Pin N 2

23 4110003075023 锁扣弹性环330532 Clamp N 2

24 4110003612003 减震垫720067 Damper mat N 2
