L956F 多路阀(120101/310004) Control valve F1204-4120006636

1 4120005894001 阀体CN211000001 Valve body N 1

2 4120005894002 端盖（限位）CN211000004 End cover N 1

3 4120005894003 端盖CN211000005 End cover N 1

4 4120005894004 浮动活塞3510300261 Piston N 1

5 4120005894005 弹簧3510904389 Spring N 1

6 4120005894006 端盖螺塞3510300128-D1 Plug N 1

7 4120005894007 O形密封圈020225N0552 Sealing ring Y 1

8 4120005894008 端盖（液控）CN211000003 End cover N 2

9 4120005894009 隔离套3510300032 Spacer sleeve N 2

10 4120005894010 O形密封圈020135N0674 Sealing ring Y 4

11 4120005894011 阀杆（动臂）3510300105 Valve rod N 1

12 4120005894012 阀杆（铲斗）3510300109 Valve rod N 1

13 4120005894013 弹簧座3510300263-D1 Spring seat N 2

14 4120005894014 弹簧3510500175 Spring N 2

15 4120005894015 弹簧座3510300262-D1 Spring seat N 2

16 4120005894016 限位螺钉3510300260 Screw N 2

17 4120005894017 螺栓GB/T5783-M8×35-8.8 Screw N 8

18 4120005894018 溢流阀分总成3519001114 Valve Y 3

19 4120005894018 溢流阀分总成3519001114 Valve Y 1

20 4120005894019 单向阀芯3510904062 Valve rod N 2

21 4120005894020 弹簧3510900078 Spring N 4

22 4120005894021 螺塞3510300051 Plug N 2

23 4120005894022 O形密封圈3912881204 Sealing ring N 2

24 4120005894023 O形密封圈0905028N0674 Sealing ring Y 1

25 4120005894024 螺塞3902800200 Plug N 1

26 4120005894025 O形密封圈3510904054 Sealing ring N 1

27 4120005894026 螺塞3510300038 Plug N 1

28 4120005894027 螺堵PCMM10047-2 Plug N 2

29 4120005894028 垫圈OR11.3*2.2* Washer N 2

30 4120005894029 活塞分总成3510300092 Piston N 1

31 4120005894030 挡圈3510500130 Retaining ring N 1
32 4120005894031 螺母GB/T6172.1-M24 Nut N 1
33 4120005894032 O形密封圈CO0625A Sealing ring N 2
34 4120005894033 阀块CN211000002 Valve block N 1
35 4120005894034 活塞3510300129 Piston N 1
36 4120005894035 弹簧3913581146 Spring N 1
37 4120005894036 垫片（0.5mm）3460500122 Shim N 1
38 4120005894037 螺塞346030082 Plug N 1
39 4120005894038 O形密封圈020114V0894 Sealing ring N 1
40 4120005894039 过渡阀块CN211000013 Valve block N 1
41 4120005894040 螺钉GB/T70.1-M8×65 Screw N 2
42 4120005894041 堵塞3510300086 Plug N 1
43 4120005894042 O形密封圈030924N0552 Sealing ring Y 1
44 4120005894043 单向阀芯3510300035 Valve rod N 2
45 4120005894044 O形密封圈030914N0552 Sealing ring Y 2
46 4120005894045 单向阀螺塞3510300036 Plug N 2
47 4120005894046 活塞帽3510300085A Cover N 1
48 4120005894047 螺钉GB/T73-M5×6 Screw N 1
49 4120005894048 弹簧CN211000047 Spring N 1
50 4120005894049 密封件3510500094 Sealing N 1
51 4120005894050 弹簧座3510300091 Spring seat N 1
52 4120005894051 O形密封圈050701N0552 Sealing ring N 1
53 4120005894052 O形密封圈020219N0552 Sealing ring Y 2
54 4120005894053 垫片（1mm）3510300266-D1 Shim N 1
