L956 散热器总成L955F-W（320204） Radiator A0394-4110003681

1 4110003681001 组合框架KZ9113726 Radiator frame N 1

2 4110003681002 防护网HB0337 Fan guard Y 2

3 4110003681003 导风罩DB0669 Fan shroud Y 1

4 4110002975206 中冷器S9112715A Air cooler Y 1

5 4110002975207 水散S9112699B Radiator Y 1

6 4110002945006 水箱盖711001 Cover Y 1

7 4110003681004 液压油散热器S9113726C Hydraulic oil cooler Y 1

8 4110002945015 法兰面螺栓614212 Screw N 26

9 4110002975215 六角头螺栓610202 Screw N 4

10 4110002943004 弹垫632300 Spring washer N 4

11 4110001688022 平垫630330 Plain washer N 8

12 4110002945016 六角螺母621200 Nut N 4

13 4110002233206 放水阀739001 Drain valve Y 1

14 4110002506023 放水管8000080800 Hose Y 1

15 4110002286007 卡箍990002 Clamp N 1

16 4110003681005 减震垫720064 Damper mat N 2

17 4110002975217 支撑杆A330514 Bracket N 1

18 4110002975218 支撑杆B330513 Bracket N 1
