L955FC 离合器K12 Clutch C0520-2905001344

1 4090000130 钢球GB308-8.5-GCr15 Ball Y 2
2 29050013911 活塞环 Piston ring Y 3
3 4021000161 轴承25590/25520/Q Bearing Y 1
4 29050014321 定位环 Locating ring Y 1
5 4110000628 轴承NTA-3446 Bearing Y 4
6 29050014041 止推垫片 Shim Y 4
7 29050014621 齿轮总成R31 Gear Y 1
8 4110000625 轴承WJ-344016 Bearing Y 2
9 29050014611 隔套 Spacer sleeve Y 1
10 29050013931 止推垫片 Shim Y 2
11 29050013841 卡环 Retaining ring Y 2
12 29050013831 卡环 Retaining ring Y 2
13 29050013851 受压盘 Pressure disc Y 2
14 29050013871 从动摩擦片 Friction disc Y 10
15 29050015511 从动摩擦片 Friction disc Y 6
16 29050013861 主动摩擦片 Friction disc Y 16
17 29050013951 隔离环 Spacer ring Y 2
18 29050013961 离合器轮毂 Clutch hub Y 1
19 29050013981 弹簧 Spring Y 1
20 29050014561 活塞环 Piston ring Y 2
21 29050014571 活塞环 Piston ring Y 2
22 29050014591 活塞 Piston Y 1
23 29050013971 活塞环 Piston ring Y 2
24 29050013991 卡环 Retaining ring Y 2
25 29050014581 隔离架 Separator Y 1
26 29050014381 K12 轴 Clutch shaft Y 1
27 29050014531 活塞 Piston Y 1
28 29050014121 弹簧 Spring Y 1
29 29050014141 离合器轮毂 Clutch hub Y 1
30 4110000626 轴承WJ-344024 Bearing Y 1

31 29050014431 齿轮总成R32 Gear Y 1

32 29050013811 止推垫片 Shim Y 1

33 29050014061 挡圈54 Retaining ring Y 1

34 4021000162 轴承33209/Q Bearing Y 1

35 4030000821 O形圈GB3452.1-77.5*3.55G-FPM O-ring Y 1

36 4030000595 油封58*72*8 Sealing ring Y 1

37 29050013471 调整垫片 Shim Y 2

38 29050013481 调整垫片 Shim Y 4

39 29050013491 调整垫片 Shim Y 6

40 29050013461 轴承保持架 Bearing seat Y 1

41 29050013451 垫片 Shim Y 6

42 4014000171 螺钉GB70.1-M8*25-8.8 Screw Y 6

43 29050026131 调整垫片 Shim Y 1
