L955FC 工作泵总成 Working pump F1100-2911001373

1 29110012981 三通块总成 T-block Y 1

2 4011001299 螺栓GB16674.1-M10*25flZnyc-8.8-480 Screw Y 4

3 29110013001 工作泵出油胶管 Hose assembly Y 1

4 29110013012 工作泵吸油钢管 Pipe N 1

5 4030000133 O形圈GB3452.1-56.0*3.55G O-ring Y 1

6 4011001653 螺栓GB16674.1-M12*80flZnyc-8.8-480 Bolt Y 4

7 4012000082 螺柱GB898-M12*35flZnyc-8.8-480 Stud Y 4

8 4013000368 螺母GB6170-M12flZnyc-8-480 Nut Y 4

9 4015000428 垫圈GB97.1-12flZnyc-300HV-480 Washer Y 4

10 4120008637 双联泵132/10 Gear pump Y 1

11 4030000633 O形圈GB3452.1-128*3.55G O-ring Y 1

12 29110001021 出油钢管 Pipe Y 1

13 4030000029 O形圈GB3452.1-37.5*3.55G O-ring Y 3

14 4011001298 螺栓GB16674.1-M10*55flZnyc-8.8-480 Screw Y 4

15 4041000056 分体法兰LGB117-312550 Flange half Y 2

16 4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 Screw Y 8

17 29110013021 工作泵吸油胶管 Hose Y 1

18 4017000006 喉箍JB8870-d100 Clamp Y 4

19 29110011921 直接头M16-M16 Nipple Y 1

20 4041000780 O形圈LGB168-11324 O-ring Y 1

21 4041003221 软管LGB129-004100 Hose assembly Y 1

22 4041001023 组合接头LGB143-01608 Nipple Y 1
