L955FC 变速箱总成 Transmission system C0500-2905003378

1 4011001280 螺栓GB5783-M10*40flZnyc-8.8-480 Screw Y 12

2 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 12

3 29050033793 VRT200变速箱总成 Transmission Y 1

4 4030000029 O形圈GB3452.1-37.5*3.55G O-ring Y 2

5 4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 Screw Y 10

6 4041000056 分体法兰LGB117-312550 Flange half Y 1

7 29050034181 加油管总成 Hose assembly Y 1

8 4011001240 螺栓GB16674-M12*25flZnyc-8.8-480 Screw Y 2

9 4120005173 液位计YWZ-100 Water level gauge Y 1

10 4011001337 螺栓GB16674.1-M12*20flZnyc-8.8-480 Screw Y 2

11 29050034171 分动箱加油管总成 Oil pipe Y 1

12 4041001562 管夹LGB122-4280 Clamp Y 1

13 4030000794 胶管JB8406-B10*400 Hose Y 1

14 4190000343 喉箍JB8870-d16 Clamp Y 6

15 4030000427 胶管JB8406-B10*1000 Hose Y 1

16 29050017381 三通块总成 Connection block Y 1

17 4011001288 螺栓GB16674.1-M10*50flZnyc-8.8-480 Screw Y 2

18 4120000139 胶管JB8406-B10*700 Hose assembly Y 1

19 4110000852 空气滤清器C-M33×2 Air cleaner Y 1

20 4011001294 螺栓GB16674.1-M10*20flZnyc-8.8-480 Screw Y 6

21 29050034731 空滤支架 Bracket Y 1

22 29050033061 分体法兰 Flange half Y 1

23 29050033761 变速箱至滤清器胶管 Hose assembly Y 1

24 4041001211 组合接头LGB143-03625 Nipple Y 2

25 4041003039 软管LGB165-014033 Hose assembly Y 1

26 4041000756 O形圈LGB168-02631 O-ring Y 2

27 4041000676 直接头LGB120-03630 Nipple Y 2

28 4110003853 传动油滤清器滤芯 Oil filter N 1

29 4110003091 滤座 Seat Y 1

30 29050034381 滤清器支架 Bracket Y 1

31 29050027531 橡胶垫 Plate Y 1
32 4120005390 空滤滤芯C-X-32 Filter insert Y 1
