L955FC 双联泵132/10(370101 ) Gear pump F1130-4120008637

1 4015000015 挡圈GB893.1-80-65Mn Retaining ring Y 1

2 4120003676001 滚动轴承 GB/T276 6307-2RS/C3 Bearing Y 1

3 4120001968002 垫圈JHM3-05 Washer Y 1

4 4120003676002 旋转轴唇型密封圈 GB9877.1-88(参考 Sealing ring Y 1

5 4120001968005 前盖JHP3-02 Cover Y 1

6 4120001968006 轴承RNA385938 Bearing Y 4

7 4120001968007 矩形密封圈JHP3-09 Sealing ring Y 1

8 4120001968009 耳形挡片JHP3-08 Retaining ring Y 2

9 4120001968010 耳形密封JHP3-07 Sealing washer Y 2

10 4120001968022 侧板1 JHP3-05(1) Side board Y 1

11 4120003676003 主动齿轮轴JHP3/02-01 Drive shaft Y 1

12 4120003676018 从动齿轮轴JHP3-03 Shaft Y 1

13 4120001968021 侧板2 JHP3-05(2) Side board Y 1

14 4120008637001 泵体Ⅰ(右旋)JHP3125/02-02(Y) Pump body Y 1

15 4120003676005 联接花键套JHP3/02-05 Bushing Y 1

16 4120008637002 螺栓JHP3-05 M16X127 Screw Y 4

17 4019000001 铆钉GB827-2*4-BL2 Rivet Y 2

18 4120005488002 标牌BP-1 Decal N 1

19 4120007939004 侧板JHP2-08 Side board Y 3

20 4120008637003 中间体(右旋)JHP3/02-03(Y) Centering block Y 1

21 4015000036 垫圈GB93-8-65Mn Spring washer Y 2

22 4014000557 E-螺钉GB70.1-M8*25EpZn-12.9 Screw Y 2

23 4015000035 垫圈GB93-6-65Mn Spring washer Y 2

24 4014000058 螺钉GB70.1-M6*20EpZn-8.8 Screw Y 2

25 4120003676008 轴承GB/T12949 20X22X20 Bearing Y 4

26 4120003676009 轴套JHP02-06 Bushing Y 2

27 4120003676010 主动齿轮轴ⅡJHP02/02-03 Drive shaft Y 1

28 4120003676011 从动齿轮轴JHP02-05 Drive shaft Y 1

29 4120003676012 泵体ⅡJHP3/02-XF-01 Pump body Y 1

30 4120003676013 耳形密封圈JHP02-10 Sealing washer Y 4

31 4120003676014 耳形档圈JHP02-11 Retaining ring Y 4
32 4120008637004 后盖JHP02-04 Cover Y 1
33 4120008637005 螺栓JHP02-09 M10X89 Screw Y 4
34 4015000025 垫圈GB93-10-65Mn Spring washer Y 4
35 4120008637006 密封件包 Sealing ring kit Y 1
