L933 转向缸总成 Steering cylinder system I2100-2921001136

1 29210010461 压板 Plate Y 1

2 29210010471 橡胶管夹 Clamp Y 1

3 4011001424 螺栓GB5782-M10*70flZnyc-8.8-480 Screw Y 1

4 4013000370 螺母GB6170-M10flZnyc-8-480 Nut Y 2

5 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 1

6 4190001834 扎丝LG13-ZS8*370 Cable tie Y 2

7 29210009721 转向缸进油胶管 Hose Y 2

8 4120005977 转向油缸HSGL-80*45*327-594 Steering cylinder Y 2

9 29210010731 钢管 Pipe Y 1

10 4030000275 O形圈GB3452.1-22.4*3.55G O-ring Y 2

11 4011001301 螺栓GB16674.1-M8*30flZnyc-8.8-480 Screw Y 4

12 4011001425 螺栓GB16674.1-M8*40flZnyc-8.8-480 Bolt Y 4

13 4041000563 软管LGB128-006078 Hose assembly Y 2

14 29210010331 钢管 Pipe Y 1
