L933 转向泵总成 Steering pump assembly I1900-2919001419

1 4120000401 工作泵CBGj3100A Gear pump Y 1

2 29110000043 泵用密封垫 Gasket Y 1

3 4012000003 螺柱GB898-M12*35EpZn-8.8 Stud Y 4

4 4013000011 螺母GB6170-M12EpZn-8 Nut Y 4

5 4015000168 垫圈GB97.1-12EpZn-300HV Washer Y 4

6 4011000475 螺栓GB16674-M10*30EpZn-8.8 Bolt Y 8

7 4041000056 分体法兰LGB117-312550 Flange half Y 1

8 4030000029 O形圈GB3452.1-37.5*3.55G O-ring Y 1

9 4011000479 螺栓GB16674-M12*30EpZn-8.8 Bolt Y 4

10 4030000235 O形圈GB3452.1-43.7*3.55G O-ring Y 1

11 4041000011 分体法兰LGB117-314650 Flange half Y 1

12 29190012451 吸油钢管 Pipe Y 1

13 29190014211 吸油胶管 Hose Y 1

14 4017000018 喉箍JB8870-d70 Clamp Y 4

15 29190014201 泵出油胶管 Hose assembly Y 1

16 4041000043 分体法兰LGB117-310490 Flange half Y 1

17 4030000026 O形圈GB3452.1-32.5*3.55G O-ring Y 1
