L933 箱体部件及附属件（370804） Case parts C0592-4110000499

1 4110000499025 箱体BD08-00001 Tank Y 1

2 4110000499107 铭牌BD08-BP01 Name plate N 1

3 4019000002 铆钉GB827-2*6-BL2 Rivet N 4

4 4110000499009 支架1BD08L-03000 Bracket Y 2

5 4011000438 螺栓GB5782-M16*80EpZn-10.9 Screw Y 8

6 4110000499108 弹簧垫圈16 01602-21648 Spring washer N 8

7 4013000016 螺母GB6170-M16EpZn-8 Nut Y 8

8 4110000960005 螺栓01010-81025 Screw Y 18

9 4015000381 垫圈GB7244-10-65Mn Washer N 57

10 4110000499026 端盖1BD08-00002 Cover Y 1

11 4110000499030 垫1BD08-00006 Gasket Y 2

12 4110000499028 调整环1BD08-00004 Adjusting ring Y 1

13 4110000499029 调整螺丝1BD08-00005 Adjuster bolt Y 2

14 4110001984058 六角螺栓M6*6 BD08-00050 Screw Y 2

15 4110000499027 止动片1BD08-00003 Retaining ring Y 2

16 4110000499031 端盖1BD08-00007 Cover Y 1

17 4110000499023 骨架油封0BIU-19822 Sealing ring Y 1

18 4110000499032 中间轴端盖1BD08-00008 Cover Y 1

19 4110000499034 垫1BD08-00010 Washer Y 1

20 4110000499033 挡油盖调整1BD08-00009 Cover Y 1

21 4110000499012 滤清器总成1BD08L-07000 Filter Y 1

22 4110000499109 六角螺栓M8*30 01010-80830 Screw Y 8

23 4110000499110 O形圈45*51*3.5 BD08-07002 O-ring Y 1

24 4110000499042 垫1BD08-00020 Washer Y 1

25 4110000499044 油底壳1BD08-00022 Oil sump N 1

26 4110000499111 吸油管BD08-00037A/B Pipe N 1

27 4110000499242 永久磁铁BD08-00038 Magnet Y 1

28 4110000218006 O 形圈07002-02434 O-ring Y 1

29 4110000218083 螺塞07044-12412 Plug Y 1

30 4110000499112 O形圈35*41*3.5 07000-03035 O-ring Y 1

31 4110000499013 加油管1BD08L-15000 Pipe Y 1

32 4110000218082 螺塞07043-00108 Plug Y 12

33 4110000499005 油管盖总成1BD08-14000 Cover Y 1

34 4110000499055 垫1BD08-00036 Washer Y 1

35 4110000499050 大端盖1BD08-00031 Cover Y 1

36 4110000499051 轴套1BD08-00032 Sleeve Y 3

37 4110000499113 垫片BD08-00033 Washer Y 1

38 4110000499052 垫1BD08-00033A Washer Y 2

39 4110000499114 外封油套BD08-10002A Bushing Y 3

40 4110000499115 进油端盖BD08-10001 Cover Y 1

41 4110000499066 端盖1BD08-10001A Cover Y 2

42 4110000499116 定位销A10*40 04020-01040 Pin Y 2

43 4014000185 螺钉GB70-M10*30EpZn-8.8 Screw Y 13

44 4110000499049 盖1BD08-00030 Cover Y 1

45 4110000499117 油封65*90*10 07012-00065 Sealing ring Y 2

46 4110000960010 螺栓Bolt M10X30 01010-81030 Screw Y 35

47 4110001984059 呼吸器总成BD08-05000A Breather cap Y 1

48 4110000499004 挡油盖1BD08-04000 Snap oil cover 1bd08-04000 Y 1

49 4110000499046 垫1BD08-00025 Washer Y 1

50 4011001187 螺栓GB5782-M10*35EpZn-10.9 Screw Y 4
