L953F 液压操纵总成 Hydraulic control system F1200-2912003255

1 4120001100 三通接头EL10LOMDA3C Three-way nipple Y 1

2 29120032571 回油钢管 Pipe Y 1

3 4030000130 O形圈GB3452.1-47.5*3.55G O-ring Y 3

4 4011001375 螺栓GB16674.1-M12*30flZnyc-8.8-480 Bolt Y 4

5 4190000143 三通接头EL12LOMDA3C Three-way nipple Y 1

6 4041001063 组合接头LGB143-01810 Nipple Y 1

7 4030000490 O形圈GB3452.1-10.0*1.80G O-ring Y 1

8 29120031441 多路阀回油胶管 Hose assembly Y 1

9 4041000011 分体法兰LGB117-314650 Flange half Y 2

10 4011001510 螺栓GB16674.1-M12*35flZnyc-8.8-480 Screw Y 12

11 29120031101 先导阀总成GDXS2-DT部装 Control lever N 1

12 29120030911 橡胶管夹 Clamp Y 1

13 29120032701 U型板固定板 Plate Y 1

14 29120030901 支架 Bracket Y 1

15 4011001299 螺栓GB16674.1-M10*25flZnyc-8.8-480 Screw Y 2

16 4011001393 螺栓GB5782-M8*100flZnyc-8.8-480 Bolt Y 2

17 4013000373 螺母GB6170-M8flZnyc-8-480 Nut Y 4

18 4015000430 垫圈GB97.1-8flZnyc-300HV-480 Washer Y 2

19 29120017721 直接头 Nipple Y 4

20 29120017731 直接头 Nipple Y 1

21 29120030751 多路阀进油胶管 Hose assembly Y 1

22 4030000029 O形圈GB3452.1-37.5*3.55G O-ring Y 3

23 4041000056 分体法兰LGB117-312550 Flange half Y 2

24 4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 Screw Y 12

25 4041000774 螺塞LGB135-01422 Plug Y 2

26 4041000767 O形圈LGB168-11124 O-ring Y 3

27 4011001558 螺栓GB5782-M12*175flZnyc-8.8-480 Screw Y 1

28 4015000428 垫圈GB97.1-12flZnyc-300HV-480 Washer Y 8

29 4013000368 螺母GB6170-M12flZnyc-8-480 Nut Y 8

30 29120009161 多路阀回油钢管 Pipe Y 1

31 4030000031 O形圈GB3452.1-42.5*3.55G O-ring Y 1

32 4011001560 螺栓GB16674.1-M10*65flZnyc-8.8-480 Screw Y 1

33 4011001465 螺栓GB5782-M12*145flZnyc-8.8-480 Screw Y 1

34 4120002278 多路阀DFSY-32-18 Control valve Y 1

35 29120015401 接头 Nipple Y 4

36 29120014931 垫圈 Washer Y 7

37 4041001451 软管LGB125-003250 Hose Y 1

38 29120007651 接头 Nipple Y 3

39 4041001007 软管LGB125-004220 Hose Y 1

40 4041001432 软管LGB125-003215 Tube lgb125-003215 Y 1

41 29120019061 多路阀进油块 Valve block Y 1

42 4011001563 螺栓GB16674.1-M10*85flZnyc-8.8-480 Screw Y 4

43 4041000604 直接头LGB120-01614 Nipple Y 1

44 4041002012 软管LGB128-004211 Hose Y 1

45 4041002411 管夹LGB169-A15*10 Clamp Y 4

46 4011001297 螺栓GB16674.1-M8*16flZnyc-8.8-480 Screw Y 4

47 29120016981 多路阀固定板 Anchor plate Y 1

48 4041001322 软管LGB125-003150 Hose assembly Y 2

49 29120017741 固定板 Anchor plate Y 1

50 4011001247 螺栓GB5783-M8*20flZnyc-8.8-480 Screw Y 2

51 4015000425 垫圈GB96.1-8flZnyc-300HV-480 Washer Y 2

52 29120016741 管夹 Clamp Y 4

53 29120016351 固定板 Anchor plate Y 2

54 4011001303 螺栓GB16674.1-M8*90flZnyc-8.8-480 Screw Y 4

55 29120017001 支架 Bracket Y 1

56 4011001294 螺栓GB16674.1-M10*20flZnyc-8.8-480 Screw Y 6

57 29120016991 固定板 Anchor plate Y 1

58 4120001954 滤油器PLF-C30*10 Hydraulic fluid filter Y 1

59 29120015081 接头 Nipple Y 2

60 4030000276 O形圈GB3452.1-32.5*2.65G O-ring Y 2

61 4041001023 组合接头LGB143-01608 Nipple Y 2

62 4030000240 O形圈GB3452.1-8.00*1.80G O-ring Y 2

63 4041001521 组合接头LGB143-11608 Nipple Y 1

64 4041002750 软管LGB124-004054 Hose assembly Y 1

65 4120005063 压力选择阀SF8-D Valve Y 1

66 4011001298 螺栓GB16674.1-M10*55flZnyc-8.8-480 Screw Y 2

67 4041002749 软管LGB126-004095 Hose assembly Y 1

68 4041002256 软管LGB124-004090 Hose assembly Y 1

69 4041001293 软管LGB124-003090 Tube lgb124-003090 Y 4

70 29120017131 先导阀进油软管 Hose assembly Y 1

71 29120033411 先导阀回油胶管 Hose assembly Y 1

72 4011001561 螺栓GB5782-M12*135flZnyc-8.8-480 Screw Y 2
