L953F 左台架总成 Platform assembiy M3430-2934004544

1 29340045501 左后扶手 Hand rail Y 1

2 29340045691 左台架 Platform Y 1

3 29340045661 左支架 Bracket Y 1

4 4011001251 螺栓GB5783-M12*45flZnyc-8.8-480 Screw Y 2

5 4043001970 防松套LGB331-12*24*16flZnyc-45 Attaching sleeve Y 2

6 4013000368 螺母GB6170-M12flZnyc-8-480 Nut Y 2

7 4011001250 螺栓GB5783-M12*30flZnyc-8.8-480 Screw Y 10

8 4015000427 垫圈GB96.1-12flZnyc-300HV-480 Washer Y 12

9 4011001243 螺栓GB5783-M12*35flZnyc-8.8-480 Screw Y 6

10 4043001383 卡子胶条LGB320-S580 Sealing strip Y 1

11 29340045481 左前扶手 Hand rail Y 1

12 4015000428 垫圈GB97.1-12flZnyc-300HV-480 Washer Y 10
