L933 变速箱操纵阀总成（330101） Shift control valve C0569-4110000499

1 4110000038340 螺钉ZL20-039011 Screw N 1

2 4110000038341 垫圈ZL20-039013 Washer N 1

3 4110000038342 弹簧ZL20-039012 Spring N 1

4 4090000119 钢球GB308-10-GCr15 Ball Y 1

5 4110000038343 防尘套 ZL20-039023（Φ10） Dust cap N 1

6 4110000038344 测压接头 ZL20-026010 Nipple N 1

7 4110000038345 测压接头垫圈 ZL20-026009 Washer N 2

8 4110002575005 六角头螺塞M10×1 Q20-01-02 Plug N 1

9 4015000222 挡圈GB893.2-30-65Mn Retaining ring Y 2

10 4110000499265 唇形密封GB9877.1-FB14*30*10 Sealing ring N 4

11 4110000038348 调整垫圈 ZL20-039010 Washer N 2

12 4110000499266 操纵滑阀ZL20-039009 Valve body N 1

13 4110000038350 防尘套 ZL20-039022 （Φ10） Dust cap N 1

14 4110000038351 螺塞 ZL20-039015 Plug N 1

15 4110000499267 O形圈GB1235-22×2.5 O-ring N 1

16 4110000038353 皮碗 ZL20-039016 Plug N 1

17 4110000038354 制动滑阀 ZL20-039017 Valve N 1

18 4110000499268 弹簧ZL20-039018X2 Spring N 1

19 4110000499269 O形圈GB1235-16*2 O-ring N 1

20 4110000038357 弹簧座 ZL20-039019 Spring seat N 1

21 4110000499270 螺塞ZL20-039021 Plug N 1

22 4110000038359 阀体 ZL20-039007 Valve N 1

23 4110000038360 纸垫 ZL20-039020 δ0.5 Gasket N 1

24 4110000038361 底板 ZL20-039008 Spacer N 1

25 4014000186 螺钉GB70-M6*16EpZn-8.8 Screw Y 15

26 4110000038362 纸垫 ZL20-030034 Gasket N 1

27 4011000451 螺栓GB5782-M10*45EpZn-8.8 Screw Y 8

28 4015000025 垫圈GB93-10-65Mn Spring washer Y 8

29 4110000038349 变速箱操纵阀总成ZL20-039000S Control valve Y 1
