L920 齿轮泵(370142) Gear pump I1901-4120000371

1 4120000171044 挡圈41060100200 Retaining ring Y 1

2 4120000171045 旋转轴唇形密封圈43020200100 Sealing ring Y 2

3 4120002117001 前盖21020200110 Cover Y 1

4 4015000245 挡圈GB893.1-52-65Mn Retaining ring Y 1

5 4120000171048 环形密封圈 44020100300 Sealing ring Y 1

6 4120000171049 滚针轴承42010100100 Needle bearing Y 4

7 4120000171050 定位套21020900110 Spacer sleeve Y 4

8 4120000171051 耳形挡片21020800110 Retaining ring Y 2

9 4120000171052 耳形密封垫21020700110 Sealing washer Y 2

10 4120000171053 侧板21020600110 Side board Y 2

11 4120000371001 主动齿轮轴HGP2050矩 21020109010 Drive shaft N 1

12 4120001084004 从动齿轮轴21020409010 Shaft Y 1

13 4120000371002 泵体HGPa2050B 21030309010 Pump body N 1

14 4120005048014 O型圈43010101500 O-ring N 1

15 4120005048013 环形密封圈 44020100400 Sealing ring N 1

16 4120000371003 后盖HGPa2050B 21030509010 Cover N 1

17 4120000371005 螺钉M16x142 01017-11642 Screw Y 4

18 4015000098 垫圈GB93-16-65Mn Spring washer Y 4

19 4014000110 螺钉GB70.1-M12*35EpZn-8.8 Screw Y 3

20 4015000026 垫圈GB93-12-65Mn Spring washer Y 3

21 4014000560 E-螺钉GB70.1-M8*30EpZn-12.9 Screw Y 2

22 4015000036 垫圈GB93-8-65Mn Spring washer Y 2

23 4120000371004 密封件包 Sealing ring kit Y 1
