L920 驻车制动总成 Parking brake syetem J2300-2923000909

1 4016000145 销轴GB882-B10*28EpZn-35 Clevis pin Y 1

2 4016000183 开口销GB91-3.2*22EpZn-Q235A Split pin Y 1

3 4011000455 螺栓GB16674-M8*25EpZn-8.8 Bolt Y 4

4 4120004349 驻车操纵机构总成LG23-920 Parking brake control Y 1

驻车操纵机构总成(130501) Parking brake, hand-op. J2310-4120004349

1 4110002042001 镀铬头LGS9530001 Release button Y 1

2 4110002042002 弹簧LGS9530004 Spring Y 1

3 4120002616001 手柄套LGS9530007 Sleeve Y 1

4 4110002042004 平垫Φ8*Φ17*1.5 PD-002-1 Washer Y 1

5 4120003754003 钢丝钩LGS9530009 Hook Y 1

6 4120003754002 手柄焊合件LGS9530000b Handle Y 1

7 4110002042008 棘钩LGS9530008 Hanger Y 1

8 4110002042007 销子Φ8*33 LGS9530006 Pin Y 1

9 4110002042019 平垫Φ8 PD-002 Washer Y 2

10 4110002042009 销子Φ8*28 LGS9530003 Pin Y 1

11 4110002042010 内接头LGS9530013 Nipple Y 1

12 4110002042014 螺栓M8-15 LGS9530011 Screw Y 1

13 4110002042020 弹垫Φ8 TD-002 Washer Y 1

14 4110002042012 销子Φ12-51 LGS9530005 Pin Y 1

15 4110002042013 平垫Φ12 PD-004 Washer Y 1

16 4110002042011 棘轮LGS9530002 Ratchet Y 1

17 4110002042016 开关罩LGS9530010 Switch box Y 1

18 4120004349001 手刹盒焊合件LGS9200000a Brake chamber Y 1

19 4110002042017 开关总成LGS9530012-001 Switch kit Y 1

20 4120004349002 拉索总成LGSR9200002 Control cable Y 1
