L920 转斗缸总成 Tilt cylinder system F1400-2914002157

1 29140000021 固定板 Anchor plate Y 1

2 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 6

3 4011001238 螺栓GB5783-M10*20flZnyc-8.8-480 Screw Y 2

4 4013000370 螺母GB6170-M10flZnyc-8-480 Nut Y 1

5 4015000025 垫圈GB93-10-65Mn Spring washer Y 1

6 29140006521 转斗指示杆 Indicator plate Y 1

7 29140000041 转斗指示板 Indicator plate Y 1

8 4041000767 O形圈LGB168-11124 O-ring Y 1

9 4041000774 螺塞LGB135-01422 Plug Y 1

10 4011001246 螺栓GB5783-M8*16flZnyc-8.8-480 Screw Y 2

11 29140006531 管夹 Clamp Y 1

12 4015000430 垫圈GB97.1-8flZnyc-300HV-480 Washer Y 2

13 4120006441 转斗油缸HSGL-100*55*412-779 Tilt cylinder Y 1

14 4030000501 O形圈GB3452.1-15.0*1.80G O-ring Y 1

15 29140010301 转斗缸大腔钢管 Pipe Y 1

16 29140006551 压板 Plate Y 1

17 4041002730 管夹LGB172-C14*50 Hose clamp Y 2

18 4011001467 螺栓GB5782-M10*80flZnyc-8.8-480 Bolt Y 2

19 29140009561 转斗缸胶管 Hose assembly Y 1

20 4041000582 直接头LGB120-02630 Nipple Y 2

21 4041000685 O形圈LGB168-12631 O-ring Y 2

22 29140009571 转斗缸胶管 Hose assembly Y 1

23 4041000187 直接头LGB120-02622 Nipple Y 1

24 4041000771 O形圈LGB168-11924 O-ring Y 1
