L920 转向泵总成 Steering pump system I1900-2919001518

1 4041000796 直接头LGB120-02628 Nipple Y 1

2 4041000779 O形圈LGB168-12331 O-ring Y 1

3 29120006551 组合直角接头 Nipple Y 1

4 4030000501 O形圈GB3452.1-15.0*1.80G O-ring Y 1

5 29190006581 泵出油胶管 Hose assembly Y 1

6 4011001301 螺栓GB16674.1-M8*30flZnyc-8.8-480 Screw Y 4

7 29190008061 压盖 Flange half Y 1

8 4030000279 O形圈GB3452.1-25.0*3.55G O-ring Y 1

9 4120000371 齿轮泵CBGjA2050 Gear pump Y 1

10 29110000043 泵用密封垫 Gasket Y 1

11 4012000082 螺柱GB898-M12*35flZnyc-8.8-480 Stud Y 4

12 4013000368 螺母GB6170-M12flZnyc-8-480 Nut Y 4

13 4015000428 垫圈GB97.1-12flZnyc-300HV-480 Washer Y 4

14 29190006591 泵吸油钢管 Pipe Y 1

15 4030000178 O形圈GB3452.1-30.0*3.55G O-ring Y 1

16 4011001298 螺栓GB16674.1-M10*55flZnyc-8.8-480 Screw Y 4

17 4017000018 喉箍JB8870-d70 Clamp Y 4

18 4120002315 吸油胶管HG4-763-51*530 Hose assembly Y 1

19 4011001466 螺栓GB5783-M16*35flZnyc-8.8-480 Bolt Y 6

20 4015000439 垫圈GB96.1-16flZnyc-300HV-480 Washer Y 6
