L920 多路阀(331007) Control valve assembly F1207-4120000365

1 4120000365201 双头螺柱JDL-20D2-05 M14*1.5*222 Stud N 1

2 4014000058 螺钉GB70.1-M6*20EpZn-8.8 Screw Y 2

3 4120000365202 双头螺柱JDL-20D2-07 M12*1.25*222 Stud N 2

4 4120000365203 螺塞JDL-20D2-01-01 Plug N 3

5 4120000365204 螺塞JDL-20D2-01-02 Plug N 3

6 4120000365205 螺堵JDL-20D2-01-03 Plug N 1

7 4120000365206 进油阀片JDL-20D2-01-04 Valve body N 1

8 4120000365207 安全阀JDL-20D2-01-05 Safety valve N 1

9 4120000365208 测压螺塞JDL-20D2-01-06 Plug N 1

10 4120000365209 定位端盖JDL-20D2-02-01 Valve cover N 1

11 4120000365210 弹簧座JDL-20D2-02-02 Spring seat N 2

12 4120000365211 定位弹簧JDL-20D2-02-03 Spring N 1

13 4120000365212 过载补油阀JDL-20D2-02-04 Valve N 2

14 4120000365213 防尘罩JDL-20D2-02-05 Sealing ring N 3

15 4120000365214 转斗阀杆JDL-20D2-02-06 Valve rod N 1

16 4120000365215 垫板JDL-20D2-02-07 Plate N 2

17 4120000365216 单向阀JDL-20D2-02-08 Non-return valve N 2

18 4120000365217 阀体JDL-20D2-02-09 Valve body N 1

19 4120000365218 单向阀弹簧JDL-20D2-02-10 Spring N 2

20 4120000365219 定位螺钉JDL-20D2-02-11 Screw N 1

21 4014000278 螺钉GB70.1-M6*25EpZn-8.8 Screw Y 2

22 4120000365220 定位端盖JDL-20D2-03-01 Valve cover N 1

23 4120000365221 定位座JDL-20D2-03-02 Valve seat N 1

24 4120000365222 弹簧JDL-20D2-03-03 Spring N 1

25 4120000365223 补油阀JDL-20D2-03-08 Valve N 1

26 4120000365224 动臂阀杆JDL-20D2-03-04 Valve rod N 1

27 4120000365225 盖板JDL-20D2-03-05 Plate N 1

28 4120000365226 阀体JDL-20D2-03-06 Valve body N 1

29 4120000365227 限位套JDL-20D2-03-07 Stop sleeve N 1

30 4120000365228 回油阀片JDL-20D2-04-01 Valve body N 1

31 4013000119 螺母GB6171-M14*1.5EpZn-8 Nut Y 2

32 4015000027 垫圈GB93-14-65Mn Spring washer Y 2

33 4090000097 钢球GB308-6-GCr15 Ball N 2

34 4013000427 P-螺母GB6176-M12*1.25EpZn-10 Nut Y 4

35 4015000026 垫圈GB93-12-65Mn Spring washer Y 4

36 4030000024 O形圈GB3452.1-26.5*2.65G O-ring Y 4

37 4030000097 O形圈GB3452.1-23.6*2.65G O-ring Y 3

38 4030001225 P-O形圈GB1235-20.3*2.4 O-ring Y 1

39 4030000493 O形圈GB3452.1-15.0*2.65G O-ring Y 1

40 4030001223 P-O形圈GB3452.1-87.5*3.55G O-ring Y 3

41 4120000365229 螺塞JDL-20D2-08 M14*1.5 Plug N 1

42 4014000237 螺钉GB70.1-M6*16-8.8 Screw Y 4

43 4015000480 P-垫圈GB859-6-65Mn Washer Y 8

44 4030001224 P-O形圈GB3452.1-19*3.55G O-ring Y 4
