L920 变速箱总成 Transmission assembly C0500-2905002790

1 29050006521 螺栓 Screw Y 4

2 4013000072 螺母GB889.2-M12*1.25EpZn-10 Lock nut Y 8

3 4110002939 传动轴P33*336 Propeller shaft Y 1

4 29050006541 螺栓 Screw Y 4

5 4110002900 变速箱BD06 Transmission N 1

6 29050006551 橡胶垫 Rubber plate Y 2

7 4011000499 螺栓GB5785-M16*1.5*70EpZn-8.8 Bolt Y 4

8 4015000181 垫圈GB97.1-16EpZn-300HV Washer Y 4

9 4013000129 螺母GB889.2-M16*1.5EpZn-8 Lock nut Y 4

10 29050006562 加油管 Hose assembly Y 1

11 29050006571 压盖 Cover Y 1

12 4011000481 螺栓GB16674-M8*30EpZn-8.8 Bolt Y 4

13 4030000152 O形圈GB3452.1-25.0*2.65G O-ring Y 1

14 4011000461 螺栓GB16674-M8*16EpZn-8.8 Bolt Y 2

15 29050006581 管夹 Clamp Y 1
