L920 变速操纵软轴 Throttle pulley D0610-4110003056

1 4190002767001 换挡手球LGH9180001 Handle ball Y 1

2 4190002767002 高低速手球LGH9180002 Handle ball Y 1

3 4110002149001 换挡手柄焊合LGH9180003 Connecting rod Y 1

4 4190002767004 高低速手柄焊合LGH9180004 Connecting rod Y 1

5 4120000084073 垫圈6 GB/T93-1987 Washer 6 gb/t93-1987 Y 2

6 4190002767006 M6×1-25螺栓LGH9330007 Bolt N 1

7 4190002767007 M6×1-30螺栓LGH9180005 Bolt N 1

8 4190002767008 齿轮轴组合件LGH9180006 Shaft Y 1

9 4190002767009 连接颈LGH9180007 Link Y 1

10 4190002767010 换挡盒焊合件LGH9180008 Box Y 1

11 4190002767011 齿条LGH9180009 Gear rack Y 2

12 4190002767012 平垫φ8 Washer Y 2

13 4190002767013 弹垫φ8 Washer Y 2

14 4110002434007 螺栓M8-50 LGH916D0001 Screw N 2

15 4110003056001 固定座4110003056-01 Seat N 1

16 4190002767016 φ8钢珠GZ-001 Ball N 2

17 4110002149005 弹簧LGH93300010 Spring Y 2

18 4190002767018 M12×1.25螺母RM-008-01 Nut rm-008-01 m12×1.25 N 2

19 4190002767019 M12×1.25-15螺栓LGH9330009 Bolt N 2

20 4190000915019 高低速软轴总成LGHR91800001 Control cable Y 1

21 4190000915020 换挡软轴总成LGHR91800002 Control cable Y 1

22 4110001119010 M6-7沉头螺栓GB/T819.2 Screw Y 3
