L920 动臂油缸(3713CH) Lifting cylinder assembly F1310-4120001153

1 4120001153020 缸筒总成24A130000 Cylinder tube Y 1

2 4120001153021 活塞杆总成24A110000 Piston rod Y 1

3 4120001153022 缸盖24A170000 Cover Y 1

4 4120001153023 衬套24S250202 50*55*20 Bushing Y 1

5 4120001153024 钢丝挡圈-孔用24C001070 D58.6*2t Retaining ring Y 1

6 4120001153025 密封件包 Sealing ring kit Y 1

7 4120001153025 密封件包 Sealing ring kit Y 1

8 4120001153025 密封件包 Sealing ring kit Y 1

9 4120001153025 密封件包 Sealing ring kit Y 1

10 4120001153026 钢丝挡圈-孔用24C001090 D65.6*2t Retaining ring Y 1

11 4120001153025 密封件包 Sealing ring kit Y 1

12 4120001153025 密封件包 Sealing ring kit Y 1

13 4120001153025 密封件包 Sealing ring kit Y 1

14 4120001153027 活塞24A180000 D90*48L Piston Y 1

15 4120001153025 密封件包 Sealing ring kit Y 1

16 4120001153025 密封件包 Sealing ring kit Y 1

17 4120005685008 螺钉-内六角凹端紧定24T908161 M8*16L Screw Y 1

18 4120001153028 尼龙块24C002110 D8*7.5 Block N 1

19 4120001153025 密封件包 Sealing ring kit Y 2

20 4120001153029 轴套24A150100 D50.2*D60*45L Bushing Y 1

21 4120006315008 固定座24C003010 Seat Y 1
