L920 前车架 Front frame K2400-2924000651

1 29240006512 前车架 Front frame Y 1

前车架附件 Front frame system K2500-2925002162

1 4016000113 开口销GB91-6.3*63EpZn-Q235A Split pin Y 1

2 29250001061 开槽螺母 Nut Y 1

3 29250006521 套 Sleeve Y 1

4 4021000050 关节轴承GB9163-GE50ES-2RS Spherical plain bearing Y 2

5 29250006531 端盖 End cover Y 2

6 4015000025 垫圈GB93-10-65Mn Spring washer Y 16

7 4011000048 螺栓GB5782-M10*50EpZn-8.8 Bolt Y 16

8 29250006541 下铰接销 Pin Y 1

9 4040000050 垫圈LGB001-12flZnyc-480 Washer Y 7

10 4011001241 螺栓GB5783-M12*25flZnyc-8.8-480 Screw Y 7

11 29250006551 上铰接销 Pin Y 1

12 29250006561 盘 Flange Y 2

13 4043000321 销轴LGB301-50*104*190G-40Cr Weld pin Y 2

14 29250001351 走线胶套 Rubber sleeve Y 4

15 4011001240 螺栓GB16674-M12*25flZnyc-8.8-480 Screw Y 10

16 4043000322 销轴LGB301-60*98*190G-40Cr Weld pin Y 2

17 4043000148 销轴LGB301-50*80*145G-40Cr Weld pin Y 1

18 29250006571 前盖板 Cover plate Y 1

19 4011001246 螺栓GB5783-M8*16flZnyc-8.8-480 Screw Y 4

20 4015000425 垫圈GB96.1-8flZnyc-300HV-480 Washer Y 14

21 29250000291 通油螺栓 Bolt Y 2

22 29250000301 垫片 Shim Y 4

23 29250007971 前转向销轴 Pin Y 2

24 4043000067 垫片LGB303-50*100*1 Shim Y 2

25 4040000008 垫圈LGB001-10 Washer Y 2

26 4011001238 螺栓GB5783-M10*20flZnyc-8.8-480 Screw Y 2

27 4043000141 垫片LGB303-60*120*2 Shim Y 4

28 4043000151 垫片LGB303-60*120*1 Shim Y 4

29 29250006581 转向销油管 Lubricating pipe Y 2

30 29250000311 管夹 Clamp Y 2

31 4014000024 螺钉GB818-M6*10EpZn-4.8 Screw Y 4

32 4015000035 垫圈GB93-6-65Mn Spring washer Y 4

33 4030000065 油杯JB7940.1-M10*1 Lubricating nipple Y 9

34 29250016151 右挡尼板 Plate N 1

35 29250011021 照灯网板 Protecting plate Y 2

36 29250022421 右灯架 Lamp bracket Y 1

37 29250012661 照灯护板 Protecting plate Y 2

38 29250022431 左灯架 Lamp bracket Y 1

39 4011001247 螺栓GB5783-M8*20flZnyc-8.8-480 Screw Y 10

40 29250016141 左挡泥板 Plate N 1
