L920 行车制动总成 Travel brake system J2200-2922002367

1 29220001251 制动器管接头 Nipple Y 4

2 4030000552 O形圈 O-ring Y 8

3 29220001261 制动器接头块 Block Y 4

4 29220011191 桥油管 Brake pipe Y 2

5 4011001295 螺栓GB16674.1-M8*25flZnyc-8.8-480 Screw Y 6

6 29220000131 三通接头 Three-way nipple Y 2

7 29220011181 桥油管 Brake pipe Y 2

8 4041002078 软管LGB153-202180 Hose Y 1

9 4041002410 管夹LGB169-A12*10 Clamp Y 1

10 4011001297 螺栓GB16674.1-M8*16flZnyc-8.8-480 Screw Y 7

11 4015000430 垫圈GB97.1-8flZnyc-300HV-480 Washer Y 1

12 4013000373 螺母GB6170-M8flZnyc-8-480 Nut Y 1

13 4041002411 管夹LGB169-A15*10 Clamp Y 1

14 29220017601 直接头 Nipple Y 3

15 29220000811 垫圈 Washer Y 7

16 4120001795 气制动阀LY60F Brake valve Y 1

17 4030000055 螺塞JB1000-M22*1.5EpZn-35 Plug Y 1

18 4041001027 软管LGB153-202046 Hose assembly Y 1

19 29220021551 后桥过渡钢管 Brake pipe Y 1

20 29220008981 压板 Plate Y 3

21 29220022651 制动软管 Hose assembly Y 1

22 4011001249 螺栓GB5783-M10*30flZnyc-8.8-480 Screw Y 4

23 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 16

24 4013000370 螺母GB6170-M10flZnyc-8-480 Nut Y 8

25 29220001231 加力泵管接头 Bolt Y 2

26 4030000551 O形圈 O-ring Y 4

27 29220001241 加力泵接头块 Nipple Y 2

28 4120001985 空气加力泵SL20 Air cylinder N 2

29 29010000041 螺栓 Screw Y 2

30 29220021561 三通管 Three-way nipple Y 1

31 4011001248 螺栓GB5783-M10*25flZnyc-8.8-480 Screw Y 4

32 29220006611 储气罐 Air tank Y 1

33 4041002731 软管LGB173-006090 Hose assembly Y 1

34 29220023681 制动气管 Hose assembly Y 1

35 4120003757 制动灯开关YK209KLA Pressure switch Y 1
