L920 变速箱输出轴部分BYD2206LQ0004(370804) Transmission output shaft C0588-4110002900

1 4110002900017 开口销04050-14030 Split pin Y 2

2 4110000218080 螺母BD05-00010 Nut Y 2

3 4110000218022 大垫圈01643-32260 Washer Y 2

4 4110000960011 O形圈07000-13032 O-ring Y 2

5 4110000218050 法兰盘BD05K-03000 Flange Y 1

6 4110002900021 骨架油封07012-00050 Sealing ring Y 2

7 4110000960006 螺栓 M12X25 01010-81225 Screw Y 4

8 4110000160054 垫圈01602-21236 Gasket Y 8

9 4110000218110 轴承座BD05-00008 Seat Y 1

10 4110002900022 O型圈105*3.1 07000-12105 O-ring Y 4

11 4021000171 P轴承GB297-30308 Roller bearing Y 2

12 4110002900023 输出齿轮BD06-00016-04 Gear Y 1

13 4110002900024 隔套BD06-00020 Spacer Y 1

14 4110002900025 隔套BD06-00019 Spacer Y 1

15 4110000218100 输出轴BD05L-00003 Output shaft Y 1

16 4110000218111 轴承座BD05L-00002 Seat Y 1

17 4110000960007 螺栓 M12X35 01010-81235 Screw Y 4

18 4110000218105 制动器支座ZL15E-00002 Seat Y 1

19 4110000013028 制动器总成BD05-14000C Brake system Y 1

20 4110000004001 弹性垫圈01602-21030 Retaining ring Y 12

21 4110002900026 螺钉01252-71030 Screw Y 4

22 4110000218049 法兰BD05K-00001 Flange Y 1

23 4110000960005 螺栓01010-81025 Screw Y 8
