L918 连杆机构 Linkage system H1500-2915000772

1 29150014851 动臂 Lifting arm Y 1
2 29150017061 摇臂 Rocker arm Y 1
3 29150007661 拉杆 Connecting rod Y 1

工作装置附件 Working equipment H1600-2916001012

1 4043000171 垫片LGB303-55*90*2 Shim Y 1

2 4043000170 垫片LGB303-55*90*1 Shim Y 1

3 29160007641 销轴 Pin Y 1

4 29160007621 压盘 Lock ring Y 1

5 4043000169 轴套LGB302-55*80B3 Bushing Y 2

6 4015000430 垫圈GB97.1-8flZnyc-300HV-480 Washer Y 12

7 4011001397 螺栓GB5783-M8*25flZnyc-8.8-480 Screw Y 12

8 29160007671 销轴 Pin Y 2

9 4043002088 轴套LGB302-50*50A2 Bushing Y 3

10 29160007631 锁销 Lock pin Y 2

11 29160007611 盖板 Cover plate Y 1

12 4043002086 轴套LGB302-60*90A2 Bushing Y 2

13 4043000137 销轴LGB301-50*75*135-40Cr Weld pin Y 4

14 4011001241 螺栓GB5783-M12*25flZnyc-8.8-480 Screw Y 6

15 4040000050 垫圈LGB001-12flZnyc-480 Washer Y 6

16 4030000065 油杯JB7940.1-M10*1 Lubricating nipple Y 9

17 4043000226 P-轴套LGB302-50*58A2 Bushing Y 2

18 4043000138 销轴LGB301-75*109*200-40Cr Weld pin Y 1

19 4043002089 轴套LGB302-75*110A2 Bushing Y 1

20 29160007691 压板 Plate Y 2

21 4015000166 挡圈GB894.1-22-65Mn Retaining ring Y 2

22 4011001593 螺栓GB5782-M16*115flZnyc-8.8-480 Screw Y 1

23 4013000393 螺母GB6170-M16flZnyc-8-480 Nut Y 2

24 4043000331 垫片LGB303-75*130*1 Shim Y 2

25 4043000332 垫片LGB303-75*130*2 Shim Y 1

26 4043000067 垫片LGB303-50*100*1 Shim Y 4

27 4043000333 垫片LGB303-50*100*2 Shim Y 2

28 4043002168 销轴LGB301-50*75*135-1200G Weld pin Y 2
