L918 转向泵总成 Steering pump system I1900-2919000774

1 4041000796 直接头LGB120-02628 Nipple Y 1

2 4041000779 O形圈LGB168-12331 O-ring Y 1

3 29120006551 组合直角接头 Nipple Y 1

4 4030000501 O形圈GB3452.1-15.0*1.80G O-ring Y 1

5 29190007751 泵出油胶管 Hose assembly Y 1

6 4011000481 螺栓GB16674-M8*30EpZn-8.8 Bolt Y 4

7 29190008061 压盖 Flange half Y 1

8 4030000279 O形圈GB3452.1-25.0*3.55G O-ring Y 1

9 4120001084 双联泵CBGj2050/1010-XF Gear pump Y 1

10 29110000043 泵用密封垫 Gasket Y 1

11 4012000003 螺柱GB898-M12*35EpZn-8.8 Stud Y 4

12 4013000011 螺母GB6170-M12EpZn-8 Nut Y 4

13 4015000168 垫圈GB97.1-12EpZn-300HV Washer Y 4

14 29190007761 泵吸油钢管 Pipe Y 1

15 4030000031 O形圈GB3452.1-42.5*3.55G O-ring Y 1

16 4011000478 螺栓GB16674-M12*55EpZn-8.8 Bolt Y 4

17 4017000018 喉箍JB8870-d70 Clamp Y 2

18 4090000042 吸油胶管HG4-763-51*490 Hose assembly Y 1

19 4011000095 螺栓GB5783-M16*35EpZn-8.8 Screw Y 6

20 4015000305 垫圈GB96.1-16EpZn-300HV Retaining ring Y 6
