L918 多路阀(331005) Control valve F1201-4120001964

1 4013000190 螺母GB6173-M14*1.5EpZn-05 Nut Y 2

2 4015000027 垫圈GB93-14-65Mn Spring washer Y 2

3 4015000479 P-垫圈GB848-14EpZn-300HV Washer Y 2

4 4120000365020 双头螺栓M14X1.5X273-DL20-8.00 Stud N 1

5 4013000137 螺母GB6173-M12*1.25EpZn-05 Nut Y 4

6 4015000026 垫圈GB93-12-65Mn Spring washer Y 4

7 4015000004 垫圈GB848-12EpZn-300HV Washer Y 4

8 4120000365022 双头螺栓M12X1.25X273-DL20-9.00 Stud N 2

9 4120000365103 进油阀体DL20-1.01a Valve body N 1

10 4030000024 O形圈GB3452.1-26.5*2.65G O-ring Y 3

11 4120000365104 螺塞DL20-7.03 Plug Y 2

12 4120000365105 内六角堵头4WN-14WD M14x1.5 Plug Y 1

13 4120000365106 螺塞DL20-7.03a Plug Y 1

14 4120000365107 安全阀XDYF25-01 Safety valve Y 1

15 4030001223 P-O形圈GB3452.1-87.5*3.55G O-ring Y 4

16 4014000058 螺钉GB70.1-M6*20EpZn-8.8 Screw Y 24

17 4015000480 P-垫圈GB859-6-65Mn Washer Y 24

18 4120001964001 定位端盖DL20-U2.06 Valve cover Y 4

19 4030001267 P-O形圈GB3452.1-34.5*2.65G O-ring Y 6

20 4120000365109 定位螺钉DL20-2.05 Screw Y 4

21 4120001964002 弹簧座DL20-U2.03 Spring seat Y 8

22 4120001964003 弹簧DL20-U2.04-Φ32 XΦ3.7 X42 Spring Y 4

23 4120000365115 二次溢流阀XDYF20-02 Relief valve Y 2

24 4120001964004 阀体DL20-U2.07 Valve body Y 1

25 4120000365043 O型滑阀DL20-2.08a-01 Valve N 2

26 4120000365117 单向阀DL20-2.02 Non-return valve Y 3

27 4120000365118 弹簧DL20-2.01 Φ11.2 *Φ0.7 *32 Spring Y 3

28 4120001964005 定位端盖ⅠDL20-U3.01 Valve cover Y 1

29 4120001964006 定位螺钉DL20-U3.03 Screw Y 2

30 4120001964007 弹簧座ⅠDL20-U3.02 Spring seat Y 2

31 4120001964008 弹簧DL20-U3.04-Φ31.7 XΦ3.9 X48.5 Spring Y 2

32 4120001964009 弹簧座ⅡDL20-U3.07 Spring seat Y 2

33 4120001964010 阀体DL20-U3.05 Valve body Y 1

34 4120001964011 Q型阀杆DL20-U3.06 Valve rod Y 1

35 4120001964012 定位端盖ⅡDL20-U3.08 Valve cover Y 1

36 4120001964013 阀体DL20-U2.07b Valve body Y 1

37 4120001964014 回油阀体DL20-7.01c Valve body Y 1

38 4120000365128 螺塞DL20-7.02 Plug Y 1

39 4030000097 O形圈GB3452.1-23.6*2.65G O-ring Y 1
