L918 变速箱总成DB55 022 001-输入轴部件(330101) Transmission assembly C0565-4110002081

1 4013000220 螺母GB810－M20*1.5EpZn－8 Nut Y 1

2 4015000285 垫圈GB858－20 Washer Y 1

3 4110000038171 垫圈 ZL20-032011 20 Washer Y 1

4 4030000178 O形圈GB3452.1-30.0*3.55G O-ring Y 1

5 4110002081040 法兰DB55 302 002 Bearing flange Y 1

6 4110002081041 防尘罩DB55 302 003 Dust cover Y 1

7 4110002081042 输入轴DB55 302 001 Input shaft Y 1

8 4110000499294 唇形密封圈GB9877.1-88 FB45*62*8 Sealing ring Y 1

9 4011000744 P螺栓GB21-M10*30-8.8 Bolt gb21-m10*30-8.8 Y 9

10 4015000025 垫圈GB93-10-65Mn Spring washer Y 9

11 4110000038038 输入轴端盖ZL20-030008 Cover plate Y 1

12 4110000038048 纸垫ZL20-030002 Paper pillow Y 1

13 4110002081043 调整垫片ZL20-032016 Shim Y 1

14 4021000167 P轴承GB297-32207 Bearing Y 2

15 4011000082 螺栓GB5783-M10*25EpZn-8.8 Bolt Y 8

16 4110002081044 止动片DB55 302 016 Retaining plate Y 4

17 4110002081045 圆柱销8m6×22 GB/T119.1-2000 Pin Y 2

18 4110002081046 齿轮DB55 302 004 Gear Y 1

19 4110002081047 离合器外壳座DB55 302 005 Housing Y 1

20 4110002081048 离合器外壳DB55 302 007 Closure Y 1

21 4110000038191 阀座 ZL20-032109 Seat Y 1

22 4090000126 钢球GB308-5-GCr15 Ball Y 1

23 4030001255 P-O形圈GB3452.1-45*2.65G O-ring Y 1

24 4110002081049 封油圈DB55 302 009 Sealing ring Y 1

25 4110002081050 活塞DB55 302 008 Piston Y 1

26 4110002081051 内摩擦片DB55 302 024 Friction disc Y 9

27 4110002081052 外摩擦片DB55 302 023 Friction disc Y 10

28 4110000076190 承压板4642308185 Anchor plate Y 1

29 4110002081054 弹性挡圈0730 513 415 Retaining ring N 1

30 4110002081055 弹簧DB55 302 012 Spring Y 1

31 4110002081056 弹簧挡板DB55 302 011 Baffle Y 1

32 4110002081057 轴用挡圈45DB55 302 019 Retaining ring Y 1

33 4021000009 滚动轴承GB276-6008 Ball bearing Y 2

34 4110002081058 孔用挡圈68 DB55 302 015 Retaining ring Y 1

35 4110002081059 齿轮DB55 302 006 Gear Y 1

36 4110002081060 轴套DB55 302 013 Bushing Y 1

37 4110002081061 调整轴套DB55 302 014 Bushing Y 1

38 4110002081062 内封油环DB55 302 010 Sealing ring Y 1

39 4110002081063 进油端盖总成DB55 202 004 Cover Y 1

40 4110002081064 纸垫DB55 302 018 Sealing ring Y 1

41 4110000038198 活塞环(Φ52)CA10-350914-A Piston ring Y 2

42 4110000038175 闷塞 ZL20-032009 9 Plug Y 1

43 4110000038199 轴端档板 Zl20-032002A Cover plate Y 1

44 4110000038203 止动垫 ZL20-032001 Spacer Y 1

45 4011000102 螺栓GB5783-M8*16EpZn-8.8 Bolt Y 2

46 4110002081096 弹性挡圈A=2,25 0730 513 420 Retaining ring Y 1

47 4110002081097 弹性挡圈A=2,30 0730 513 419 Retaining ring Y 1

48 4110002081098 弹性挡圈A=2,35 0730 513 418 Retaining ring Y 1

49 4110002081099 弹性挡圈A=2,40 0730 513 417 Retaining ring Y 1

50 4110002081100 弹性挡圈A=2,45 0730 513 416 Retaining ring Y 1

51 4110002081101 弹性挡圈A=2,50 0730 513 180 Retaining ring Y 1

52 4110002081102 弹性挡圈A=2,20 0730 513 421 Retaining ring Y 1

53 4110002081103 弹性挡圈A=2,15 0730 513 455 Retaining ring Y 1
