Air condition aggregate N 3500-2935001412

1 29350010611 空调出风口 Air duct Y 1

2 29350010601 空调接口风道 Air duct Y 1

3 4011001343 螺栓G B16674.1-M 6*12flZnyc-8.8-480 Screw Y 3

4 29350010321 进水管 H ose Y 1

5 4017000024 环箍Q C390-D 26 Clam p Y 4

6 29350010311 出水管 H ose Y 1

7 29310022301 橡胶套 Rubber sleeve Y 2

8 4190000019 扎丝LG 13-ZS3*150 Cable tie Y 5

9 29350013501 支架 Bracket Y 1

10 29350010291 过渡管 Copper tube Y 1

11 4011001341 螺栓G B5783-M 8*40flZnyc-10.9-480 Screw Y 2

12 4015000430 垫圈G B97.1-8flZnyc-300H V -480 W asher Y 7

13 4013000384 螺母G B889.1-M 8flZnyc-8-480 N ut Y 1

14 29350011041 支架 Bracket Y 1

15 4011001340 螺栓G B16674.1-M 8*50flZnyc-10.9-480 Screw Y 3

16 4110000347 压缩机皮带A17-410 Belt Y 1

17 28250005602 走线胶套 Rubber cover Y 1

18 29350011401 管卡 Clam p Y 1

19 4011001246 螺栓G B5783-M 8*16flZnyc-8.8-480 Screw Y 1

20 4011001296 螺栓G B16674.1-M 8*20flZnyc-8.8-480 Screw Y 6

21 4015000433 垫圈G B97.1-10flZnyc-300H V -480 W asher Y 4

22 4011001248 螺栓G B5783-M 10*25flZnyc-8.8-480 Screw Y 4

23 29350011952 L958F空调系统 Air conditioning unit Y 1

24 29350012571 支架 Bracket Y 1

25 29350010241 支架 Bracket Y 1

26 4011001238 螺栓G B5783-M 10*20flZnyc-8.8-480 Screw Y 4

27 4015000426 垫圈G B96.1-10flZnyc-300H V -480 W asher Y 4

28 4017000007 喉箍JB8870-d60 Clam p Y 1

29 4014000536 螺钉G B70.1-M 10*130flZnyc-10.9-480 Screw Y 1

30 4015000433 垫圈G B97.1-10flZnyc-300H V -480 W asher Y 2

31 4011001342 螺栓G B5783-M 8*130flZnyc-10.9-480 Screw Y 1

32 4015000440 垫圈G B849-8flZnyc-480 W asher Y 1

33 29350011051 固定块 Block Y 1

34 29350011061 垫片 Shim Y 1

35 4013000394 螺母G B889.1-M 10flZnyc-8-480 N ut Y 1

36 29350011121 垫片 Shim Y 2

37 14402470 压缩机 Com pressor Y 1

L958F空调系统 Air conditioning unit N 3550-2935001195

1 4011000107 螺栓G B5783-M 8*30EpZn-8.8 Bolt Y 2

2 4015000036 垫圈G B93-8-65M n Spring washer Y 2

3 4015000072 垫圈G B97.1-8EpZn-300H V W asher Y 2

4 4190003109 蒸压管 H ose Y 1

5 4190003108 压冷管 H ose Y 1

6 4130002904 蒸发器总成 Evaporator Y 1

7 4019000023 扎丝 LG 13-ZS4*185 Cable tie Y 2

8 4190002766 排水管组件 W ater pipe Y 2

9 4130002701 冷凝器总成 Condenser Y 1

10 4190003088 贮蒸管 H ose Y 1

11 4130002529 空调线束 W iring harness Y 1

12 4190002765 压力开关 Switch Y 1

13 4011000276 螺栓G B5783-M 6*25EpZn-8.8 Bolt Y 3

14 4015000035 垫圈G B93-6-65M n Spring washer Y 3

15 4015000207 垫圈G B97.1-6EpZn-300H V W asher Y 3

16 4130002528 电磁阀总成 V alve Y 1

17 4130002905 控制面板 Panel Y 1
