液压操纵总成 H ydraulic control system F1200-2912003704

1 29120037111 多路阀KM 300-III-19A部装A Control valve N 1

2 29120034961 液压操纵主管路和先导管路 H ydraulic control N 1

3 29120034981 先导油源阀组部装 H ydraulic control N 1

4 29120029501 先导阀PCL403-35-B部装总成 Control lever assem bly N 1

5 4011001300 螺栓G B16674.1-M 10*30flZnyc-8.8-480 Screw Y 20

6 4030000029 O 形圈G B3452.1-37.5*3.55G O -ring Y 1

7 4041000056 分体法兰LG B117-312550 Flange half Y 1

8 4120007563 接头G E25S15/8U N O M D CF N ipple Y 1

9 4120002172 过渡接头EW 25SO M D CF N ipple Y 1

10 29120034921 合流胶管 H ose assem bly Y 1

11 4041000766 直接头LG B120-01818 N ipple Y 1

12 4041000768 O 形圈LG B168-11524 O -ring Y 1

13 4041000011 分体法兰LG B117-314650 Flange half Y 3

14 4030000130 O 形圈G B3452.1-47.5*3.55G O -ring Y 3

15 4011001510 螺栓G B16674.1-M 12*35flZnyc-8.8-480 Screw Y 12

16 29120037081 回油钢管 Pipe Y 1

17 4041002979 软管LG B164-005170 H ose assem bly Y 1

18 4041001795 软管LG B161-014077 Tube lgb161-014077 Y 1

19 4041002377 管夹LG B169-A20*12.5 Clam p Y 1

20 4011001294 螺栓G B16674.1-M 10*20flZnyc-8.8-480 Screw Y 2

21 4120001100 三通接头EL10LO M D A3C Three-way nipple Y 1

22 4041002256 软管LG B124-004090 H ose assem bly Y 1

23 4041002371 软管LG B126-004128 H ose assem bly Y 1

24 4041002417 管夹LG B169-B20*12.5 Clam p Y 1

25 29120015081 接头 N ipple Y 2

26 4030000276 O 形圈G B3452.1-32.5*2.65G O -ring Y 2

27 4120001954 滤油器PLF-C30*10 H ydraulic fluid filter Y 1

28 4041001023 组合接头LG B143-01608 N ipple Y 1

29 4030000240 O 形圈G B3452.1-8.00*1.80G O -ring Y 1

30 4041000574 软管LG B125-004115 H ose assem bly Y 1

31 4041000026 分体法兰LG B117-310491 Flange half Y 4

32 4030000026 O 形圈G B3452.1-32.5*3.55G O -ring Y 4

33 4041000818 防尘盖LG B134-01049 Cover Y 4

34 4120005540 换向阀SV 08-20M S-6T-N -24ER Control valve Y 1

35 4011001284 螺栓G B16674.1-M 6*40flZnyc-8.8-480 Screw Y 2

36 4120004696 直通接头1CO -16-06 N ipple Y 2

37 4041000812 软管LG B124-004085 H ose Y 1

38 4011001238 螺栓G B5783-M 10*20flZnyc-8.8-480 Screw Y 4

39 4015000433 垫圈G B97.1-10flZnyc-300H V -480 W asher Y 5

40 29120029541 滤油器固定板 Plate Y 1

41 4041000774 螺塞LG B135-01422 Plug Y 4

42 4041000767 O 形圈LG B168-11124 O -ring Y 4

43 4011001248 螺栓G B5783-M 10*25flZnyc-8.8-480 Screw Y 3

44 29120034901 油路块总成 Block Y 1

45 4120001954001 滤芯（先导滤清器滤芯)PLFX-30X10 Filter insert Y 1
