L918 转向缸总成 Steering cylinder system I2100-2921001126

1 4011000366 螺栓JB999-M181.540EpZn-35 Bolt Y 4
2 4030000058 垫圈JB1002-18-T2 Washer Y 8
3 29210004031 钢管 Pipe Y 1
4 4120001821 转向油缸HSGL-6335300-520 Steering cylinder Y 2
5 29210010471 橡胶管夹 Clamp Y 1
6 29210010461 压板 Plate Y 1
7 4011001424 螺栓GB5782-M10*70flZnyc-8.8-480 Screw Y 1
8 4013000370 螺母GB6170-M10flZnyc-8-480 Nut Y 2
9 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 2
10 29210011271 转向缸进油胶管 Hose assembly Y 2
11 29210006521 转向缸中间胶管 Hose assembly Y 2
12 29210004021 钢管 Pipe Y 1

转向油缸(3713CH) Steering cylinder I2110-4120001821

1 4120001821201 活塞杆 Piston rod Y 1
2 4120001821202 密封件包 Sealing ring kit Y 1
3 4120001821202 密封件包 Sealing ring kit Y 1
4 4120001821202 密封件包 Sealing ring kit Y 1
5 4120001821202 密封件包 Sealing ring kit Y 2
6 4120001821202 密封件包 Sealing ring kit Y 1
7 4120001821202 密封件包 Sealing ring kit Y 1
8 4120001821202 密封件包 Sealing ring kit Y 1
9 4120001821203 缸盖 Cover Y 1
10 4120001821204 缸体 Cylinder Y 1
11 4120001821205 活塞 Piston Y 1
12 4120001821202 密封件包 Sealing ring kit Y 1
13 4120001821202 密封件包 Sealing ring kit Y 1
14 4120001821202 密封件包 Sealing ring kit Y 1
15 4120001821202 密封件包 Sealing ring kit Y 1
16 4120003179016 螺钉GB77-M8×10 Screw Y 1
17 4090000126 钢球GB308-5-GCr15 Ball Y 1
18 4021000248 关节轴承GB9163-GE35ES Spherical plain bearing Y 1
19 4015000272 P挡圈GB893.1-55-65Mn Retaining ring Y 1
20 4120001821206 衬套 Bushing Y 1
