L918 行车制动总成 Travel brake system J2200-2922002534

1 29220001251 制动器管接头 Nipple Y 4

2 4030000552 O形圈 O-ring Y 8

3 29220001261 制动器接头块 Block Y 4

4 29220021481 前桥右油管 Brake pipe Y 1

5 4041002412 管夹LGB169-A20*10 Clamp Y 1

6 4011001297 螺栓GB16674.1-M8*16flZnyc-8.8-480 Screw Y 3

7 29220010161 三通接头 Three-way nipple Y 2

8 4011001295 螺栓GB16674.1-M8*25flZnyc-8.8-480 Screw Y 9

9 4190000176 过渡接头EW10LOMDA3C Nipple Y 2

10 29220021501 前桥左油管 Brake pipe Y 1

11 29220025931 制动软管 Hose assembly Y 1

12 4041003045 软管LGB128-005136 Hose assembly Y 2

13 4190000141 接头EW12LOMDA3C Nipple Y 7

14 4120004421 串联踏板阀06-466-220 Brake valve N 1

15 4190000147 接头GE12L9/16UNFOMDA3C Nipple Y 6

16 4041002956 软管LGB166-005050 Hose assembly Y 1

17 4041003046 软管LGB166-005045 Hose assembly Y 1

18 4041000766 直接头LGB120-01818 Nipple Y 2

19 4041000768 O形圈LGB168-11524 O-ring Y 2

20 4041001495 软管LGB165-005110 Hose assembly Y 1

21 4041000831 直接头LGB120-01816 Nipple Y 2

22 4041000780 O形圈LGB168-11324 O-ring Y 2

23 4041000885 软管LGB127-005050 Hose Y 1

24 29220018971 滤油器支架 Bracket Y 1

25 4011001294 螺栓GB16674.1-M10*20flZnyc-8.8-480 Screw Y 4

26 4120004417 压力油过滤器PLF-H110*10 Hydraulic fluid filter Y 1

27 29220012581 变径接头 Nipple Y 2

28 4030000894 O形圈GB3452.1-43.7*2.65G O-ring Y 2

29 29220025771 制动软管 Hose assembly Y 1

30 29220009221 接头块 Block Y 1

31 4120004340 制动尾灯压力开关 Switch Y 1

32 4011001305 螺栓GB16674.1-M8*45flZnyc-8.8-480 Screw Y 2

33 4041002254 软管LGB128-004040 Hose assembly Y 1

34 29220020892 后桥左油管 Brake pipe Y 1

35 29220020912 后桥右油管 Brake pipe Y 1

36 4041001765 软管LGB128-005040 Hose assembly Y 3

37 29220017621 直接头1-1/16-12UN-M18 Nipple Y 1

38 29220019151 过渡接头 Nipple Y 1

39 4120008121 行车制动低压报警开关PS61-FS105BARF Pressure switch Y 1

40 29220009261 螺栓 Bolt Y 2

41 4015000427 垫圈GB96.1-12flZnyc-300HV-480 Washer Y 2

42 4120004397 双路充液阀06-463-432 Check valve Y 1

43 4190000149 接头GE12L3/4UNFOMDA3C Nipple Y 3

44 4011001240 螺栓GB16674-M12*25flZnyc-8.8-480 Screw Y 2

45 29220025391 支架 Bracket Y 1

46 4190000143 三通接头EL12LOMDA3C Three-way nipple Y 2

47 4120002703 接头GE12LR3/4EDOMDA3C Nipple Y 2

48 29230010611 蓄能器固定板-114 Plate Y 2

49 4120002705 蓄能器PED1-1.0L-31.5 Accumulator Y 2

50 29120017111 缓冲套 Rubber sleeve Y 2

51 29230009811 橡胶垫 Rubber mat Y 2

52 29220025841 盖板 Plate Y 1

53 4120004417001 压力油过滤器滤芯LH0110D010BN/HC Filter insert Y 1
