L918 空调 Air conditioning system N3500-2935001341

1 4011001248 螺栓GB5783-M10*25flZnyc-8.8-480 Screw Y 7

2 4015000426 垫圈GB96.1-10flZnyc-300HV-480 Washer Y 12

3 29350011481 左支撑架 Bracket Y 1

4 4110000347 压缩机皮带A17-410 Belt Y 1

5 4011001405 螺栓GB5783-M8*40flZnyc-8.8-480 Screw Y 2

6 4015000430 垫圈GB97.1-8flZnyc-300HV-480 Washer Y 2

7 4041002386 管夹LGB169-B25*12.5 Clamp Y 6

8 4015000425 垫圈GB96.1-8flZnyc-300HV-480 Washer Y 3

9 4011001397 螺栓GB5783-M8*25flZnyc-8.8-480 Screw Y 3

10 4043001353 卡子胶条LGB320-U350 Sealing strip Y 1

11 29350011491 右支撑架 Bracket Y 1

12 29350013501 支架 Bracket Y 1

13 4190000019 扎丝LG13-ZS3*150 Cable tie Y 10

14 29310022301 橡胶套 Rubber sleeve Y 2

15 29350010311 出水管 Hose Y 1

16 29350010321 进水管 Hose Y 1

17 29350013382 空调系统 Air conditioning unit Y 1

18 29350010231 支架 Bracket Y 1

19 29350010601 空调接口风道 Air duct Y 1

20 29350010241 支架 Bracket Y 1

21 4011001296 螺栓GB16674.1-M8*20flZnyc-8.8-480 Screw Y 8

22 4011001343 螺栓GB16674.1-M6*12flZnyc-8.8-480 Screw Y 3

23 29350010291 过渡管 Copper tube Y 2

24 4017000024 环箍QC390-D26 Clamp Y 4

25 4011001240 螺栓GB16674-M12*25flZnyc-8.8-480 Screw Y 2

26 29350013421 压缩机支架 Bracket Y 1

27 4011001342 螺栓GB5783-M8*130flZnyc-10.9-480 Screw Y 1

28 4015000388 垫圈GB849-8 Washer Y 1

29 29350011051 固定块 Block Y 1

30 29350011041 支架 Bracket Y 1

31 4011000311 螺栓GB5782-M10*135EpZn-8.8 Screw Y 1

32 4013000370 螺母GB6170-M10flZnyc-8-480 Nut Y 2

33 4015000436 垫圈GB97.1-16flZnyc-300HV-480 Washer Y 2

34 4011000511 螺栓GB5782-M16*120EpZn-8.8 Screw Y 1

35 4011000840 螺栓GB5782-M16*55EpZn-8.8 Screw Y 1

36 4011001238 螺栓GB5783-M10*20flZnyc-8.8-480 Screw Y 2

37 29350010611 空调出风口 Air duct Y 1

38 14402470 压缩机 Compressor Y 1

39 4011001285 螺栓GB5783-M6*16flZnyc-8.8-480 Screw Y 6

40 4015000424 垫圈GB97.1-6flZnyc-300HV-480 Washer Y 6
