L918 快换装置液压总成 Quick-change equipment hydraulic system G1820-2918001444

31 4041000592 软管LGB125-004055 Hose assembly Y 1
32 29180010721 快换操纵标志 Decal Y 1

1 4120008469 快换油缸HSGL-30*20*185-685 Cylinder Y 1

2 4041002970 直接头LGB177-01410 Nipple Y 2

3 4041002971 矩形圈LGB176-01012 Ring Y 2

4 4041001047 组合接头LGB143-01406 Nipple Y 2

5 4041002022 软管LGB128-403043 Hose assembly Y 2

6 4041000133 直接头LGB120-01414 Nipple Y 2

7 4041000767 O形圈LGB168-11124 O-ring Y 8

8 4120001741 液压锁BQ2201-7E Check valve Y 1

9 4014000615 螺钉GB70.1-M8*55flZnyc-8.8-480 Screw Y 2

10 4041000604 直接头LGB120-01614 Nipple Y 6

11 4041002594 软管LGB127-204125 Hose Y 2

12 29180007971 快换联钢管 Pipe Y 2

13 4011001405 螺栓GB5783-M8*40flZnyc-8.8-480 Screw Y 2

14 4015000430 垫圈GB97.1-8flZnyc-300HV-480 Washer Y 2

15 29180007961 固定压板 Plate Y 4

16 4041002892 软管LGB127-404082 Hose Y 2

17 29180014311 过渡钢管 Pipe Y 2

18 4011001288 螺栓GB16674.1-M10*50flZnyc-8.8-480 Screw Y 2

19 4013000370 螺母GB6170-M10flZnyc-8-480 Nut Y 2

20 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 2

21 29180013981 固定压板 Plate Y 4

22 4041002013 软管LGB127-004033 Hose Y 2

23 4041001023 组合接头LGB143-01608 Nipple Y 3

24 29180014301 电磁阀固定板 Bracket Y 1

25 4011001295 螺栓GB16674.1-M8*25flZnyc-8.8-480 Screw Y 4

26 29180015471 液压软管-2300 Hose assembly Y 1

27 4120002171 三通接头ET12LOMDCF Three-way nipple Y 1

28 4120000368 电磁阀4WE6E61B/CG24NZ4B08 Solenoid valve Y 1

29 4014000513 螺钉GB70.1-M8*30flZnyc-8.8-480 Screw Y 4

30 29180007862 电磁阀座 Valve seat Y 1
