L918 转斗油缸HSGL-10055377-779(3713CH) Tilt cylinder assembly F1410-4120008468

1 4120008468001 缸筒总成24A142570 Cylinder tube N 1

2 4120006960003 活塞杆总成24A114350 Piston rod Y 1

3 4120006539003 缸盖24C105130 Cover Y 1

4 4120006442004 衬套24S255251 55*60*25 Bushing Y 1

5 4120006539004 钢丝挡圈-孔用24C090120 Retaining ring Y 1

6 4120006960004 密封件-缓冲24H005504 Sealing N 1

7 4120006742004 密封件-活塞杆24F205503 Sealing ring N 1

8 4120008468002 挡圈-U形圈24E00551C Retaining ring Y 1

9 4120000602122 密封件-防尘 24D205512 Sealing ring Y 1

10 4120006539006 钢丝挡圈-孔用24C090160 Retaining ring Y 1

11 4120006742006 O形圈24K10950A O-ring N 1

12 4120008468003 挡圈-O形圈24M11000C Retaining ring N 1

13 4120006603013 O形圈24K310001 O-ring N 1

14 4120006539007 活塞24C106120 Piston Y 1

15 4120006742007 O形圈24K10550A O-ring N 1

16 4120008468004 挡圈-O形圈24M10600C Retaining ring N 1

17 4120006603016 密封件-活塞24P210002 Sealing ring kit N 1

18 4120006742009 支承环24G210001 Support ring N 2

19 4120006603018 钢球24U004001 Ball Y 1

20 4120006316010 螺钉-内六角凹端紧定24T906121 M6*12L Screw Y 1

21 4120006960006 轴套24C116340 Bushing Y 2

22 4120006960007 固定座24A154270 Anchor plate Y 1

23 4120006308008 垫圈24T401002 Piston washer Y 2

24 4120008468005 螺栓-六角头，全螺纹24TB10254 Bolt N 2

25 4120008468006 密封件包24A104650S Sealing kit Y 1
