L918 快换电气系统 Quick coupler electric system G1830-2937002455

1 4130001833 快换开关JK931-01KH Rocker switch Y 1

2 29370024461 快换线束 Wiring harness Y 1

3 4190001839 扎丝LG13-ZS4*160 Cable tie Y 10

4 4130001290 倒车蜂鸣器FM211C Buzzer Y 1

5 4011000461 螺栓GB16674-M8*16EpZn-8.8 Bolt Y 1

连杆机构 Linkage system H1500-2915003174

1 29150007661 拉杆 Connecting rod Y 1

2 29150017061 摇臂 Rocker arm Y 1

3 29150031682 动臂 Lifting arm Y 1

工作装置附件 Working equipment H1600-2916001021

1 4043000657 销轴LGB301-50*82*150-40Cr Weld pin Y 2

2 4043000069 O形圈LGB308-88*8 O-ring Y 4

3 4043000330 垫片LGB303-50*90*2 Shim Y 2

4 4043000032 垫片LGB303-50*90*1 Shim Y 4

5 4043003884 销轴LGB301-55*N*445-1N00Y Pin Y 1

6 4043002168 销轴LGB301-50*75*135-1200G Weld pin Y 2

7 4043000067 垫片LGB303-50*100*1 Shim Y 4

8 4043000333 垫片LGB303-50*100*2 Shim Y 2

9 4043000137 销轴LGB301-50*75*135-40Cr Weld pin Y 2

10 4043002086 轴套LGB302-60*90A2 Bushing Y 2

11 4043000138 销轴LGB301-75*109*200-40Cr Weld pin Y 1

12 4043000331 垫片LGB303-75*130*1 Shim Y 2

13 4043000332 垫片LGB303-75*130*2 Shim Y 1

14 4043000169 轴套LGB302-55*80B3 Bushing Y 2

15 4043002088 轴套LGB302-50*50A2 Bushing Y 3

16 4011001241 螺栓GB5783-M12*25flZnyc-8.8-480 Screw Y 8

17 4040000050 垫圈LGB001-12flZnyc-480 Washer Y 8

18 4043002089 轴套LGB302-75*110A2 Bushing Y 1

19 4030000065 油杯JB7940.1-M10*1 Lubricating nipple Y 9

20 4043000226 P-轴套LGB302-50*58A2 Bushing Y 2
