后退档过渡齿轮总成 G ear set C0520-2905001454

1 29050013541 轴 Shaft Y 1
2 29050015471 垫圈8 W asher Y 5
3 4011000725 螺栓G B5783-M 8*30-8.8 Screw Y 5
4 29050013561 隔套 Spacer sleeve Y 1
5 4021000157 轴承N J208ECP Bearing Y 2
6 29050013552 齿轮R71 G ear Y 1
7 29050013571 垫片 Shim Y 1

离合器K12 Clutch C0520-2905002519

1 29050014381 K12 轴 Clutch shaft Y 1
2 29050013911 活塞环 Piston ring Y 3
3 4021000161 轴承25590/25520/Q Bearing Y 1
4 29050014321 定位环 Locating ring Y 1
5 4110000628 轴承N TA-3446 Bearing Y 4
6 4110000625 轴承W J-344016 Bearing Y 2
7 29050024001 齿轮总成R31 G ear Y 1
8 29050014611 隔套 Spacer sleeve Y 1
9 29050013951 隔离环 Spacer ring Y 2
10 29050013961 离合器轮毂 Clutch hub Y 1
11 29050013981 弹簧 Spring Y 1
12 29050014591 活塞 Piston Y 1
13 29050014581 隔离架 Separator Y 1
14 29050014571 活塞环 Piston ring Y 2
15 29050014141 离合器轮毂 Clutch hub Y 1
16 29050014531 活塞 Piston Y 1
17 29050014121 弹簧 Spring Y 1
18 29050013871 从动摩擦片 Friction disc Y 10
19 29050013861 主动摩擦片 Friction disc Y 16
20 29050015511 从动摩擦片 Friction disc Y 6
21 29050013851 受压盘 Pressure disc Y 2
22 29050014431 齿轮总成R32 G ear Y 1
23 29050013841 卡环 Retaining ring Y 2
24 29050013831 卡环 Retaining ring Y 2
25 29050014041 止推垫片 Shim Y 4
26 29050013811 止推垫片 Shim Y 1
27 29050014061 挡圈54 Retaining ring Y 1
28 4021000162 轴承33209/Q Bearing Y 1
29 4030000821 O 形圈G B3452.1-77.5*3.55G -FPM O -ring Y 1
30 29050013491 调整垫片 Shim Y 6

31 29050013481 调整垫片 Shim Y 4
32 29050013471 调整垫片 Shim Y 2
33 29050013461 轴承保持架 Bearing seat Y 1
34 29050013451 垫片 Shim Y 6
35 4014000171 螺钉G B70.1-M 825-8.8 Screw Y 6 36 4030000595 油封5872*8 Sealing ring Y 1
37 4110000626 轴承W J-344024 Bearing Y 1
38 29050013931 止推垫片 Shim Y 2
39 29050013971 活塞环 Piston ring Y 2
40 29050013991 卡环 Retaining ring Y 2
41 29050014561 活塞环 Piston ring Y 2
42 4090000130 钢球G B308-8.5-G Cr15 Ball Y 2
43 29050026131 调整垫片 Shim Y 1
