分动箱总成 Transfer gearbox C0520-2905001564

1 4041001264 O 形圈LG B168-22331 O -ring Y 1

2 4041001057 螺塞LG B135-02732 Plug Y 1

3 4030000058 垫圈JB1002-18-T2 W asher Y 1

4 4041000508 螺塞LG B135-01824 Plug Y 1

5 29050015651 输出轴总成 Shaft N 1

6 29050015911 分动箱壳体 D rop box housing Y 1

7 29050015841 1/2档总成 G ear changing unit Y 1

8 29050016271 3/4档总成 G ear changing unit Y 1

9 29050016281 中间轴总成 D rive shaft N 1

10 4030000804 O 形圈G B3452.1-28.0*2.65G -FPM O -ring Y 1

11 4041000140 直接头LG B155-02730 N ipple Y 1

12 29050016161 固定板 Anchor plate Y 1

13 4015000288 垫圈G B1230-12EpZn-45 W asher Y 9

14 4011000064 螺栓G B5782-M 12*50EpZn-8.8 Bolt Y 9

15 29050015851 密封垫 G asket Y 1

16 29050015871 油标尺 O il dipstick Y 1

17 4030000805 O 形圈G B3452.1-5.60*2.65G -FPM O -ring Y 1

18 29050015861 油标尺座 Pipe retainer Y 1

19 4011000101 螺栓G B5783-M 6*20EpZn-8.8 Bolt Y 4

20 29050015461 垫圈6 W asher Y 4

1/2档总成 Shaft and clutch assem bly C0520-2905001584

1 4011000195 螺栓G B5783-M 8*35EpZn-8.8 Bolt Y 5

2 29050015471 垫圈8 W asher Y 5

3 29050016091 盖 Cover Y 1

4 29050016101 密封垫 G asket Y 1

5 4011000935 螺栓G B5782-M 12*45-8.8 Screw Y 2

6 4015000288 垫圈G B1230-12EpZn-45 W asher Y 2

7 29050016031 锁紧板 Lock plate Y 1

8 4021000153 轴承N U P311ECJ Bearing Y 1

9 4015000270 挡圈G B893.1-120-65M n Retaining ring Y 1

10 29050015892 齿轮 R33 G ear Y 1

11 4030000872 O 形圈G B3452.1-32.5*3.55G -FPM O -ring Y 1

12 29050016191 堵塞 Plug Y 1

中间轴总成 D rive shaft C0520-2905001628

1 29050015902 齿轮 R51 G ear Y 1

2 29050015921 轴 Shaft Y 1

3 4021000151 轴承529X/522 Bearing Y 2

4 29050016061 调整垫片 Shim Y 2

5 29050016071 调整垫片 Shim Y 4

6 29050016081 调整垫片 Shim Y 6

7 29050016051 轴承套 Bearing bushing Y 1

8 4030000814 O 形圈G B3452.1-112*3.55G -FPM O -ring Y 1

9 4041000777 螺塞LG B135-02227 Plug Y 1

10 4041001265 O 型圈LG B168-21924 O -ring Y 1

11 4011000106 螺栓G B5783-M 8*25EpZn-8.8 Bolt Y 6

12 29050015471 垫圈8 W asher Y 6

13 29050026161 调整垫片 Shim Y 1

3/4档总成 Shaft and clutch assem bly C0520-2905001627

1 29050016111 齿轮 R43 G ear Y 1

2 4015000241 挡圈G B893.1-110-65M n Retaining ring Y 1

3 4021000154 轴承6212/C3 Bearing Y 1

4 4015000155 挡圈G B894.1-60-65M n Retaining ring Y 1

5 29050016121 密封垫 G asket Y 1

6 4019000025 铆钉G B827-3*10-BL2 Rivet Y 2

7 29050016181 板 Plate Y 1

8 29050016131 轴承套 Bearing bushing Y 1

9 4015000288 垫圈G B1230-12EpZn-45 W asher Y 2

10 4011000795 螺栓G B5786-M 12*1.25*30EpZn-8.8 Screw Y 2

11 29050016141 透气管 Tube Y 1

12 4011000106 螺栓G B5783-M 8*25EpZn-8.8 Bolt Y 8

13 4030000827 O 形圈G B3452.1-103*3.55G -FPM O -ring Y 1

14 29050016151 盖 Cover Y 1

15 29050015471 垫圈8 W asher Y 8
